SDW01-4-RFP3H Truck/Trailer Parking Sensor

The SDW01-4-RFP3H Waterproof Parking Sensor System is designed for trucks and trailers, ensuring safe and accurate reversing.
With 4 IP68-rated SmartSensors, it offers a 0–2.5m detection range, advanced self-diagnosis, and strong anti-interference performance.
The LED display with buzzer and digital readout provides clear distance alerts, while its durable automotive-grade connectors and 10–35V DC compatibility make installation reliable and versatile.

warranty time： 3 years
voltage： 10-35V
dimensions： Black
sample： support

Download Annex

Parameters

warranty time： 3 years
voltage： 10-35V
dimensions： Black
sample： support

Product Detail

Truck/Trailer Parking Sensor System

Model No.: SDW01-4-RFP3H

1) Truck/Trailer Waterproof Rear 4 Parking Sensor System;
2) Sensor detection range: 0cm~2.5m;
3) Display range: 45cm~2.5m;
4) Advanced self-diagnosis with error indication;
5) All weather design, waterproof level: IP68;
6) 4*RFP3H SmartSensor module built in double angle sensor, fit for metal tube bumper use, Automotive connector type;

7) Precision accuracy: CM;

8) DSP01 display, 3 color LED 4 channel / buzzer built-in & digital readout;
9) Power Input: 10~35V DC;

10) Industrial cables and connectors, Microchip MCU.

Wiring Diagram
